Benefits
· Portable multi-process machine, MMA, Lift TIG, MIG/MAG, high efficient inverter
· Over current / over voltage / over load protection
· User friendly panel, self explanatory operation
· Compatible with spool gun with current control
Features
· Digital mode, MCU Control, good arc characteristic
· 2/4 T trigger mode, suitable for long / short seam
· Powerfull expert database system, just select the built in job list for the application
Specifications
· Technical Specification
· Rated Input Voltage / Frequency (Hz) : 1phase 230V + 15%, 50-60 Hz
· Rated Input Capacity (kVA) : 9.7
· Rated Input Current (A) : 42
· Duty Cycle (400C) : 35%@200A
· OCV (V) : 63/13.6 (VRD ON)
· Protection Class : IP21S
· Insulation Class : F
· Dimension (MM) : 410X210X438
· Weight (Kg/lb) : 15.8 / 35
· GMAW :
· Output Voltage Range (V) : 10 – 24
· Trigger Mode : 2 / 4T
· Wire Feed Method : Push / Pull
· Wire Size (MM) : 0,6 /0,8 /1,0
· TIG :
· Output Current Range (A) : 10 – 200
· Arc Ignition Method : Lift Arc
· Trigger Mode : 2 / 4T
· MMA :
· Output Current Range (A) : 10 – 200
