Mitutoyo Screw Micrometer 25-50/0.01MM 125-106
SCREW MICROMETER 25-50/0.01MM 125-106
Product Detail
Benefits -
- Fixed anvil type.
- It directly indicates screw pitch diameter,meaning no need for calculation.
Features
- V-anvil and conical spindle for measuring pitch diameters of screwthreads
- Vernier scale in metric units for taking precise outsidediameter (OD) measurements
- Ratchet-stop mechanism helps provideuniform pressure for precise, repeatable measurement
- Sati n chromefinish on thimble and sleeve helps resist rust and reduce glare
- Hammertone, baked enamel finish for protection and durabil ity of frame
Specifications
- Range : 25-50
- Accuracy : 2µm
- Graduation : 0.01 mm
- Spindle feed error : 3µm
Technical Spec
- Netto Weight - 0.250 KG
- Unit dimension - 11 X 20 X 3.5 CM
- Height dimension - 3.500
- Length dimension 19.800
- Width dimension 10.500
- Material Steel
- Type Screw Micrometer
- Lead Time 170
- Dimension uom 19.800
