Pferd Grinding Wheel E115-7A24LPSF 64085

Grinding Wheel E115-7A24LPSF 640852

Benefits

• General purpose tool of hardness grade L.
• PFERD product characterized by aggressive grinding performance and long tool life. A combination tool for steel and stainless steel that optimizes inventory management.
• Abrasive: Aluminium oxide A Manufactured without addition of ferrous, sulphurous or chlorinated fillers.
• Workpiece materials: Steel, stainless steel (INOX)
• Application: Surface grinding, work on weld seams, chamfering, fillet weld grinding
• Recommendation for use: Suitable for use on angle grin ders of all output categories, Achieves particularly high stock removal rates even at low contact pressure.

Features

• EN Designation: Designation and shape of the tool

• 1 = Grinding wheel, fl at type
• 6 = Cylindrical cup wheels
• 11 = C up wheel, tapered type
• 27 = Grinding wheel, depressed centre type
• 29 = Semi-fl exible grinding wheel, depressed centre type Abrasive
• A = Aluminium oxide
• AC = Aluminium oxide/silicon carbide
• C = Silicon carbide
• C O = Ceramic grit
• Z = Zirconia alumina
• ZA = Zirconia alumina/al uminium oxide
  Grit size
• Grit size acc. to ISO 8486
  Hardness grade (wheel properties)
• Very soft: K, H
• Soft: L, M, N
• Medium-Hard: P, O, Q
• Hard: R, S
• Very hard: T
  Bond
• BF = Resinoi d bond, fi bre-reinforced, woven or non-woven
• B = Resin oid bond and other duroplastic bonds
  Max. operating speed in (m/s)

Specifications

• Diameter: 115 mm
• Thickness: 7.2 mm
• Hole: 22.23 mm
• Max speed: 13300 Rpm
• EN designation: 27 A 24 L BF 80
• Grit size: 24

Technical Spec

• Netto Weight 0.168 KG
• Unit Dimension 11.5 X 11.5 X 0.7 CM
• Height Dimension 0.700
• Length Dimension 11.500
• Width Dimension 11.500
• Type PS Forte
• Lead Time 22
• Dimension uom 11.500
